Case Report

Primary cavernous hemangioma of the thyroid
Meryem Ilkay Eren Karanis1, Arif Atay2, Ilknur Kucukosmanoglu1, Cevdet Duran3, Alpaslan Sahin2
1MD, Konya Training and Research Hospital, Department of Pathology, Konya, Turkey.
2MD, Konya Training and Research Hospital, Department of General Surgery, Konya, Turkey.
3Associate Professor, Konya Training and Research Hospital, Department of Internal Medicine, Division of Endocrinology and Metabolism, Konya, Turkey.

doi:10.5348/ijcri-201560-CR-10521

Address correspondence to:
Cevdet Duran
MD, Associate Professor, Department of Internal Medicine
Endocrinology and Metabolism,Konya Training and Research Hospital
42100, Konya
Turkey
Phone: +90 332 2210000
Fax: +90 332 3236723

Access full text article on other devices

  Access PDF of article on other devices

[HTML Abstract]   [PDF Full Text] [Print This Article]
[Similar article in Pumed] [Similar article in Google Scholar]


How to cite this article
Eren Karanis MI, Atay A, Kucukosmanoglu I, Duran C, Sahin A. Primary cavernous hemangioma of the thyroid. Int J Case Rep Images 2015;6(6):352–355.


Abstract
Introduction: Hemangiomas are common benign vascular tumors. Primary thyroid cavernous hemangiomas are extremely rare and have been reported only as case reports in literature. In this report, a case with thyroid cavernous hemangioma was reported.
Case Report: A 45-year-old female with history of enlarging anterior neck mass referred to our clinic. Ultrasonography showed a single hypoechogenic nodule in the right lobe of the thyroid. Right hemi-thyroidectomy was performed and cavernous hemangioma was diagnosed.
Conclusion: Preoperative differential diagnosis thyroid hemangioma is very difficult. Surgery should be indicated when malignancy or cavernous hemangioma is suspected or compressive symptoms developed and it provides a good prognosis.

Keywords: Cavernous hemangioma, Nodular goiter, Thyroid, Vascular tumor


Introduction

Hemangiomas are common benign vascular tumors composed of blood vessels of various size lined by plump to flattened endothelial cells with no atypia [1]. Cavernous hemangiomas are common in children and adults and tend to invade the upper half of the body and mostly seen in cutaneous tissue, and it can be located in the deep soft tissue and in organs. Primary thyroid cavernous hemangiomas are very rare and have been reported in limited case reports [2]. Secondary hemangioma may occur as a result of repeated fine-needle aspiration biopsy (FNAB) [3].

Herein, we report a case with primary thyroid cavernous hemangioma.


Case Report

A 45-year-old female was referred to our clinic with enlarging anterior neck mass for six months. She had no compressive symptoms, history of trauma, previous fine-needle aspiration biopsy or other invasive neck procedures. There was no family history of thyroid diseases. On physical examination, hard, painless, mobile mass was detected in thyroid region. Serum thyroid stimulating hormone and free T4 levels were normal, and no antithyroid antibodies were detected. Ultrasonography (USG) showed a single hypoechogenic mass in the right lobe of the thyroid with a size of 41x60x65 mm in diameter. There were neither abnormal findings in the left lobe nor in cervical lymph nodes. Right hemithyroidectomy was performed and macroscopically; 5.5 cm in diameter, well-circumscribed encapsulated nodular lesion was extracted. Cross-sectional surface of nodular lesion was hemorrhagic in most areas, with patchy areas of fibrosis and myxoid change (Figure 1). Touch imprint method was applied to the nodular lesion and microscopically, intensive blood cells, and some small number of swollen endothelial cells were seen (Figure 2). On histopathology; the nodular lesion was composed of large, cystically dilated, anastomosing blood vessels that were filled with blood cells and lined by flat endothelium without atypia (Figure 3) and degenerative areas were also seen. Endothelial cells stained with immunohistochemical CD34 stain (Figure 4). As a result, primary cavernous hemangioma of the thyroid was diagnosed.

The patient was discharged from the hospital two days after surgery with no signs of complications. The patient currently remains asymptomatic 10 months after the operation.


Cursor on image to zoom/Click text to open image
Figure 1: Macroscopic appearance of the thyroid cavernous hemangiomas: Well-circumscribed nodular lesion with hemorrhagic cut surface in most areas, irregular areas of fibrosis and myxoid change.



Cursor on image to zoom/Click text to open image
Figure 2: Intensive blood cells and only very small number of swollen endothelial cells in touch imprint preparations (H&E stain, x50)



Cursor on image to zoom/Click text to open image
Figure 3: Microscopic appearance of the thyroid cavernous hemangiomas: Large, cystically dilated, anastomosing blood vessels in the right part of the picture and thyroid follicules in the left part of the picture (H&E stain, x50)



Cursor on image to zoom/Click text to open image
Figure 4: Immunohistochemical CD34 positivity in endothelial cells (CD34, x50).



Discussion

Hemangiomas are one of the most common soft tissue tumors. They are benign and composed of various sized blood vessels, lined by plump to flattened endothelial cells with no atypia. Cavernous hemangiomas are common in children and adults. Cavernous hemangiomas tend to hold the upper half of the body and mostly seen in cutaneous tissue, else it can be located in the deep soft tissue and in organs [1].

Primary cavernous hemangiomas of the thyroid are very rare. In most cases, thyroid gland hemangiomas may be considered as a consequence of vascular proliferation that follows the organization of a hematoma after a trauma or FNAB and such hemangiomas of the thyroid are named secondary thyroid hemangioma. [3]. Primary thyroid hemangiomas are considered to be a developmental anomaly [4]. A few cases of primary cavernous hemangioma of the thyroid gland have been reported [5]. We evaluated the case as primary thyroid cavernous hemangiomas because there are no history of trauma, previous FNAB or other invasive neck procedures.

Primary thyroid hemangiomas mostly seen as asymptomatic cervical mass. In the presence of intra-tumoral bleeding, fast growing masses could also be seen [6]. Most of the reported thyroid hemangiomas are located in left lobe, and are slightly higher in males [2]. Our case is women and the tumor was located in the right lobbe of the thyroid.

Due to no specific pathognomonic findings on USG, and FNAB or computed tomography, diagnosis of cavernous hemangioma of the thyroid mostly cannot be made preoperatively. It is suggested by Shpitzer et al., that magnetic resonance imaging, single photon emission computed tomography, digital subtraction angiography and red blood cell scans can be useful for the preoperative diagnosis of hemangiomas [7]. Though, these methods are not used routinely because of their high cost and inaccessibility [8]. Most of the published cases, were able to get diagnosed by histopathologic examination after surgery [9].

In thyroid hemangiomas, FNAB provides intensive blood cells and are insufficient for diagnosis. Although not useful in the diagnosis of thyroid hemangiomas, FNAB is recommended for excluding of the other thyroid tumors [2].

If a thyroid nodule is suspicious for malignancy or there is presence of signs of compression, surgical treatment is proposed. Total thyroidectomy or hemithyroidectomy could be carried out for the treatment [10]. Surgical treatment provides a good prognosis at thyroid hemangiomas.


Conclusion

In conclusion, primary cavernous hemangioma of thyroid is quite rare and benign. Preoperative differential diagnosis is very difficult. Surgery should be indicated when malignancy or cavernous hemangioma is suspected or compressive symptoms developed and it provides a good prognosis. A definitive diagnosis can only be achieved by postoperative histopathological evaluation.


References
  1. Srivastana A. Capillary, Venous and Cavernous Hemangiomas. In: Mentzel T, Montgomery EA, Thway K, Lucas DR, Cassarino DS, Srivastava A. Eds. Diagnostic Pathology Soft Tissue Tumors. 1st ed. Canada: Amirsys; 2011. p. 6–9.    Back to citation no. 1
  2. Dasgupta A, Teerthanath S, Jayakumar M, Hs K, Raju M. Primary cavernous haemangioma of the thyroid - a case report. J Clin Diagn Res 2014 Feb;8(2):151–2.   [CrossRef]   [Pubmed]    Back to citation no. 2
  3. Tsang K, Duggan MA. Vascular proliferation of the thyroid. A complication of fine-needle aspiration. Arch Pathol Lab Med 1992 Oct;116(10):1040–2.   [Pubmed]    Back to citation no. 3
  4. Kumar R, Gupta R, Khullar S, Dasan B, Malhotra A. Thyroid hemangioma: A case report with a review of the literature. Clin Nucl Med 2000 Oct;25(10):769–71.   [CrossRef]   [Pubmed]    Back to citation no. 4
  5. Kumamoto K, Sugano K, Hoshino M, Utsumi Y, Suzuki S, Takenoshita S. Cavernous hemangioma of the thyroid. Thyroid 2005 Oct;15(10):1199–201.   [CrossRef]   [Pubmed]    Back to citation no. 5
  6. Datta R, Venkatesh MD, Nilakantan A, Joseph B. Primary cavernous hemangioma of thyroid gland. J Postgrad Med 2008 Apr-Jun;54(2):147–8.   [CrossRef]   [Pubmed]    Back to citation no. 6
  7. Shpitzer T, Noyek AM, Witterick I, et al. Noncutaneous cavernous hemangiomas of the head and neck. Am J Otolaryngol 1997 Nov-Dec;18(6):367–74.   [CrossRef]   [Pubmed]    Back to citation no. 7
  8. Lee J, Yun JS, Nam KH, Chung WY, Park CS. Huge cavernous hemangioma of the thyroid gland. Thyroid 2007 Apr;17(4):375–6.   [CrossRef]   [Pubmed]    Back to citation no. 8
  9. Maciel LM, Gomes PM, Magalhães PK, Mello Filho FV, Conti-Freitas LC. A giant primary hemangioma of the thyroid gland. J Clin Endocrinol Metab 2011 Jun;96(6):1623–4.   [CrossRef]   [Pubmed]    Back to citation no. 9
  10. Ciralik H, Citil R, Bulbuloglu E, Bakaris S. A patient with a neck mass. Neth J Med 2008 Jan;66(1):38–9.   [Pubmed]    Back to citation no. 10
