Introduction: Radiation-induced osteomyelitis or osteoradionecrosis of the jaw bone is one of the most severe adverse effects of radiotherapy sometimes experienced by head and neck cancer patients. We report on the observed radiographic changes after proton radiotherapy for a patient with squamous cell carcinoma in the mandibular bone.
Case Report: We report on a case of a deeply infiltrating squamous cell carcinoma in the mandible and treated with the proton beam radiotherapy. We describe the radiographic changes of the mandible after proton beam therapy. Primary lesion disappeared and the obvious resorption of the left mandible was observed. However, the images after proton beam therapy showed continued new bone formation and regeneration of the cortical bone of the mandible.
Conclusion: This case illustrates the new bone formation and regeneration of the cortical bone of the mandible after the proton beam radiotherapy. Careful observations in more cases need to verify whether the effect of the proton beam radiotherapy maintaining a given dose while decreasing unnecessary dose to surrounding normal tissue is demonstrated or not.

Keywords: Bone regeneration, Osteoradionecrosis, Proton beam radiotherapy, Radiation-induced osteomyelitis

One of the adverse effects of radiotherapy for head and neck cancer is radiation-induced osteomyelitis or osteoradionecrosis (ORN) of the jaw bone. A lot of clinical and physical factors have been reported to be associated with the risk of ORN. They include patient-, tumor-, and treatment-related variables [1][2]. Tolerance dose of the mandibular bone was reported from 60–72 Gy [3]. Fujita et al. reported that a total dose of 90 Gy or more and a dose rate of 0.55 Gy/h or higher were associated with a significant increase in the incidence of ORN at the brachytherapy for oral tongue cancer [4]. Oral health status is a risk factor for ORN, and oral health care is an important element in the prevention of ORN. Good oral conditions before and after radiotherapy for all irradiated head and neck cancer patients are very important to prevent ORN [2][5]. The multidisciplinary team communications like the consultation of dentists or dental hygienists before the radiotherapy are commonly recommended. The managements of ORN are reported such as a conservative management, ultrasound therapy, hyperbaric oxygen [6][7]. In any case, once ORN occurred, it often can persist for a long time and be hard to manage.

Owing to the physical characteristics depositing the bulk of the radiation dose in a highly confined area of the proton beam, some lesions became treatable with the proton beam radiotherapy even if it was the treatment-resistant tumors in sensitive location [8]. Numerous studies have reported on ORN resulting from radiotherapy with X-rays. However, few reports exist on ORN resulting from proton beam radiotherapy. We report on the observed radiographic changes after proton radiotherapy for a patient with squamous cell carcinoma in the mandibular bone.

A 60-year-old male was referred to the department of oral and maxillofacial surgery with a history of persistent swelling on the left side of his face. He has been presenting with soft swelling of the left cheek and sub-mandibular region for two weeks. He was also experiencing paresthesia of the third division of the trigeminal nerve, and had limited range of motion of the jaw. The lower left second molar had been extracted and the socket was covered with soft granulation tissue. Histopathological diagnosis was based on a biopsy of the gingiva confirmed squamous cell carcinoma.

Panoramic radiography at the initial visit showed a moss-eaten appearance of the left mandible (Figure 1). Computed tomography (CT) scan revealed a well-enhanced mass and bone destruction of the left mandible (Figure 2). Initially, a surgical approach for treatment was considered. However, after 18F-fluorodeoxyglucose positron emission tomography of the region, the case was deemed inoperable as tumor invasion into the cranial fossa and was suspected along the trigeminal nerve. The patient was thus treated with chemotherapy (cisplatin and 5-fluorouracil) and proton beam therapy to 70 Gy in 35 fractions.

A panoramic image one month after proton beam therapy is shown in (Figure 3). At that time, there was obvious resorption and deformity in the left mandible. The images of cone-beam computed tomography (CBCT) one month after proton radiotherapy (Figure 4) showed a possible trabecular bony formation at the location of the primary lesion. The cortical bone once adjacent to the lesion was nearly destroyed.

A panoramic image at 10th month post-proton beam therapy (Figure 5) showed a defect where the left mandible (and tumor) had originally existed and the first molar presented as a floating tooth. Computed tomography scan images at 10th month after proton beam therapy (Figure 6) showed continued new bone formation and regeneration of the cortical bone of the mandible.

The patient experienced extreme occlusal dysfunction as a result of the bone resorption, which was exacerbated at meal times. The patient had a local recurrence one year after proton beam therapy and perished about 19 months after proton beam therapy and 26 months after the first visit.

Proton beam therapy is one of the most technologically advanced forms of radiotherapy. Protons differ from traditional megavoltage X-ray radiotherapy owing to the characteristic Bragg peak of a proton beam. The Bragg peak can be described as the deposition of energy at a specific depth in the body as the protons decelerate. The Bragg peak can be placed at any depth in the body (corresponding to a tumor location), depending on the energy of the beam selected. Conventional radiation therapy faces challenges from side effects because of a relatively high entrance dose as well as a non-zero exit dose. By contrast, proton therapy has a substantially lower entrance dose and no exit dose that reduces damage to healthy tissue surrounding a tumor [9]. In addition to differences in dose deposition; protons have different radiobiological properties compared with photons. Specifically, the relative biological effectiveness (RBE) of protons beam is considered to be 1.1, compared with 1.0 for photons. The head and neck squamous cell carcinoma observed in this case was well suited for proton therapy owing to the improved dose deposition and RBE.

The radiographic features of ORN have many similarities to those of chronic osteomyelitis [10]. An early characteristic change due to therapeutic doses of radiation is a well-defined area of bone resorption within the outer cortical plate of the mandible. Late changes are quite variable and may be predominantly osteolytic or osteosclerotic, or a mixture. Typically, the periphery of a lesion is ill-defined, and the cortical bone of the jaws shows irregular resorption. New periosteal bone formation is uncommon. For comparison, the radiographic findings of the present case and relevant published data resulting from X-ray radiotherapy are given in Table 1 [11]. Published data from patients treated with X-ray radiotherapy showed sequestrum formation, and the present case also demonstrated an unclear trabecular bone sequestrum formation in the mandible. However, the presentation of this formation in this case was different than what is typically observed with osteoradionecrosis resulting from X-ray radiotherapy. Sequestral formations typically occur in the normal bone areas of the jaw as a result of X-ray radiotherapy. In the present case, the new bone formation started in the mandible where bone resorption had occurred because of the lesion. The amount of new bone formation was very small in the present case and showed a sequestrum formation without bone trabeculae upon CT imaging. With time, it may have been possible to more clearly observe the cancellous and cortical bone on CT images and the trabecular pattern might have been observable with long-term follow-up. However, as the patient passed away 19 months after proton beam therapy, we were not able to observe such radiographic changes. For this reason, we were unable to identify whether the new bone formation observed was a sequestrum. In the present case, the mandible was almost destroyed by the cancerous invasion, but any surviving osteoblasts would have proliferated and led to the bone formation after the proton beam therapy had eliminated the cancer cells.

We compared the radiographic findings of ORN resulting from X-ray radiotherapy with those of ORN from proton beam radiotherapy. One of the main factors in choosing a form of radiotherapy (X-rays or protons) is the physiological state of the disease. Conventional radiotherapy was not indicated for the present case because the lesion had infiltrated deep into the mandibular bone. Osteoradionecrosis resulting from X-ray radiotherapy typically occurs secondary to the treatment of the primary lesion. In the present case, as the primary lesion had extensively infiltrated the mandibular bone, it was assumed that the mandibular bone was concurrently absorbed with the reduction of the lesion resulting from proton beam radiotherapy. Future investigations should consider the radiation-induced changes to bone separately whether or not the primary lesion exists in the bone.

Most lesions in the bone do not qualify for curative radiotherapy with X-rays. Typically, radiotherapy is used as a palliative treatment for pain relief or reduction of paralysis risk in patients with bone metastasis. Therefore, it is difficult to predict if the bone absorbed because of the presence of a cancerous lesion will or will not experience new bone formation in the area of the destructed lesion. With the advent of proton beam radiotherapy, the number of diseases which can be curatively treated has increased. As more patients with cancers in the jaw bone are treated with protons, careful observation of any radiation-induced effects such as osteoradionecrosis need to be monitored, classified, and disseminated appropriately.

1. Jereczek-Fossa BA, Orecchia R. Radiotherapy-induced mandibular bone complications. Cancer Treat Rev 2002 Feb;28(1):65–74.   [CrossRef]   [Pubmed]
2. Katsura K, Sasai K, Sato K, Saito M, Hoshina H, Hayashi T. Relationship between oral health status and development of osteoradionecrosis of the mandible: A retrospective longitudinal study. Oral Surg Oral Med Oral Pathol Oral Radiol 2008 Jun;105(6):731–8.   [CrossRef]   [Pubmed]
3. Emami B, Lyman J, Brown A, et al. Tolerance of normal tissue to therapeutic irradiation. Int J Radiat Oncol Biol Phys 1991 May 15;21(1):109–22.   [CrossRef]   [Pubmed]
4. Fujita M, Hirokawa Y, Kashiwado K, et al. An analysis of mandibular bone complications in radiotherapy for T1 and T2 carcinoma of the oral tongue. Int J Radiat Oncol Biol Phys 1996 Jan 15;34(2):333–9.   [CrossRef]   [Pubmed]
5. Reuther T, Schuster T, Mende U, Kübler A. Osteoradionecrosis of the jaws as a side effect of radiotherapy of head and neck tumour patients: A report of a thirty year retrospective review. Int J Oral Maxillofac Surg 2003 Jun;32(3):289–95.   [CrossRef]   [Pubmed]
6. Rice N, Polyzois I, Ekanayake K, Omer O, Stassen LF. The management of osteoradionecrosis of the jaws: A review. Surgeon 2015 Apr;13(2):101–9.   [CrossRef]   [Pubmed]
7. Jacobson AS, Buchbinder D, Hu K, Urken ML. Paradigm shifts in the management of osteoradionecrosis of the mandible. Oral Oncol 2010 Nov;46(11):795–801.   [CrossRef]   [Pubmed]
8. Leeman JE, Romesser PB, Zhou Y, et al. Proton therapy for head and neck cancer: Expanding the therapeutic window. Lancet Oncol 2017 May;18(5):e254–65.   [CrossRef]   [Pubmed]
9. Morimoto K, Demizu Y, Hashimoto N, et al. Particle radiotherapy using protons or carbon ions for unresectable locally advanced head and neck cancers with skull base invasion. Jpn J Clin Oncol 2014 May;44(5):428–34.   [CrossRef]   [Pubmed]
10. White SC, Pharoah MJ. Oral Radiology Principles and Interpretation. 6ed. Missouri: Mosby Inc; 2009. p. 337–40.
11. Suei Y. Radiographic findings of bisphosphonate-related osteomyelitis of the jaw: Investigation of the diagnostic points by comparison with radiation osteomyelitis, suppurative osteomyelitis, and diffuse sclerosing osteomyelitis. Oral Radiol 2013;29(2):121–34.   [CrossRef]
