Internal hernias are very rare accounting for about 1% of all hernias [1]. Add to that, herniation through defects of the broad ligament of the uterus is even rarer (5% of internal hernias) [2]. The broad ligament of the uterus is one of the structures which fix the position of the uterus (along with the round ligament of the uterus, transverse cervical ligament and uterosacral ligament). This hernia can be caused by congenital abnormality, pregnancy, pelvic inflammatory disease, aging and so on.

We report a difficult case to diagnose the hernia from the clinical features and were anxious about the surgical indications.

A 49-year-old woman presented with intermittent abdominal pain around her umbilicus and nausea. There was no rebound tenderness and abdominal guarding. She had the symptoms for a half day before coming to our hospital. She had myoma of the uterus and cavernous hemangioma but had never undergone surgery. Laboratory findings showed only slight leukocytosis, and X-ray showed a few dilated small bowel loops in the abdomen. We found the same distended small bowel loops in the CT scan (Figure 1).

The patient was admitted to Department of Surgery, Juntendo Shizuoka Hospital, Shizuoka, Japan with ileus and treated with fast transfusion (fluid resuscitation) and nasogastric tube. From the tube, we found drainage of about 400–500 ml/day.

Four days later, her stomachache had worsened, so we did another X-ray and CT scan (Figure 2).

Laboratory results had not changed (only leukocytosis was found) and there was no indication of intestinal disorders. We found an increase in the size of the small bowel loops with air on the X-ray. The CT scan showed distended loops and fluid in the Douglas' pouch. There was large volume ascites in the abdomen, so we decided to operate for the ileus.

For her safety, we selected a laparotomy. At surgery, we saw the ascites (serous) about 700 ml. The small intestines were edematous, the mesentery was strangulated by the fallopian tube and the blood flow to the intestine was decreased.

We resected the fallopian tube and proper ligament of the ovary and released the hernia. We washed the intraperitoneal with warm saline solution. We did not need to resect the intestine because of the recovery of the blood flow (Figure 2C-E).

The postoperative course was uneventful and the patient was discharged on day-8.

Internal hernias are rare and are classified into seven groups; paraduodenal, foramen of Winslow, pericecal, intersigmoid, transmesenteric, transomental and retroanastomotic [3]. Of internal hernias, the paraduodenal type is the most common (30–53%) [4]. An internal hernia of the broad ligament is an extremely rare cause of small bowel obstruction [1] [2].

The causes of the type of hernia can be roughly divided into two types; congenital (ruptured cystic structures reminiscent of the mesonephric or mullerian ducts) and acquired (operative trauma, pregnancy and birth trauma, or prior pelvic inflammatory disease) [5]. In addition, the type of hernia often occurs on the left side because of the defect of the broad ligament [6].

Hunt classified hernias into two types; fenestra and pouch [7]. The fenestra type is an internal hernia that goes through the broad ligament, on the other hand the pouch type is formed by a defect in the anterior or posterior aperture. Our case was a fenestra type hernia.

We found cases in the literature illustrating the effectiveness of CT scan for the diagnosis of internal hernia of the broad ligament. Symptom included (i) distended loops with air-fluid level in the Douglas' pouch, (ii) distended loops pushing against uterus, rectum and sigmoid colon, and (iii) convergence of the mesentery and blood vessels for the uterus [8]. In our case, the patient had no history of surgery.

We saw the leukocytosis in her laboratory report, but were not able to get other useful information from it.

On admission, CT scan showed only enlargement of a portion of the small intestine, so there was no indication of internal broad ligament hernia. We retrospectively checked the CT scan which had been performed four days after admission and noticed the distended bowel loops pushed against the uterus, rectum and sigmoid colon. We could see the convergence of the mesentery and blood vessels on the uterus. It is said that the certain features of the CT scan are very useful for the diagnosis [8]. However, the CT scan which had been performed on admission did not have the features.

It was very important to check the chronological change after hospitalization. We found the change in her condition and consequently were able to treat her.

Internal hernia of the broad ligament has no characteristic physical symptoms, so a CT scan is very valuable in diagnosis. We should not hesitate to take CT scans repeatedly, even if the first image does not have specific features. If the condition is diagnosed in advance, the operation can be performed using laparoscope.

We can see the effectiveness of laparoscopy for this type of hernia in the literatures [9] [10]. Laparoscopic surgeries result in a better postoperative course and shorter hospitalization than open surgeries [11].

We treated a case of an internal broad ligament hernia which was difficult to diagnose. Computed tomography (CT) is very useful for diagnosing of such cases. The CT scan which was performed in our case showed the features of the hernia retrospectively. We should keep this condition in mind when we treat women with ileus.

1. Cleator IG, Bowden WM. Bowel herniation through a defect of the broad ligament. Br J Surg 1972 Feb;59(2):151–3.   [CrossRef]   [Pubmed]
2. Karaharju E, Hakkiluoto A. Strangulation of small intestine in an opening of the broad ligament. Int Surg 1975 Aug;60(8):430.   [CrossRef]
3. Hansmann GH, Morton SA. Intra-abdominal hernia: report of a case and review of the literature. Arch Surg 1939;3:973–86.
4. Khan MA, Lo AY, Vande Maele DM. Paraduodenal hernia. Am Surg 1998 Dec;64(12):1218–22.   [Pubmed]
5. Guillem P, Cordonnier C, Bounoua F, Adams P, Duval G. Small bowel incarceration in a broad ligament defect. Surg Endosc 2003 Jan;17(1):161–2.   [CrossRef]   [Pubmed]
6. Slezak FA, Schlueter TM. Hernia of the broad ligament. In: Nyhus LM, Condon RE eds. Hernia. 4ed. Philadelphia: JB Lippincott; 1995. P. 491–7.
7. Hunt AB. Fenestrate and pouches in the broad ligament as an actual and potential cause of strangulated intra-abdominal hernia. Surgery Gynecology & Obstetrics 1934;58:906–13.
8. Suzuki M, Takashima T, Funaki H, Radiologic imaging of herniation of the small bowel through a defect in the broad ligament. Gastrointest Radiol 1986;11(1):102–4.   [CrossRef]   [Pubmed]
9. Marraoui W, Petitcolin V, Bros S, Slim K, Garcier JM, Da Ines D. Internal hernia of the broad ligament: CT diagnosis for laparoscopic management. Diagn Interv Imaging 2012 Jul;93(7-8):621–4.   [CrossRef]   [Pubmed]
10. Takayama S, Hirokawa T, Sakamoto M, Takahashi H, Yamamoto M, Sato M, Manabe T. Laparoscopic management of small bowel incarceration caused by a broad ligament defect: report of a case. Surg Today 2007;37(5):437–9.   [CrossRef]   [Pubmed]
11. Ghosheh B, Salameh JR. Laparoscopic approach to acute small bowel obstruction: review of 1061 cases. Surg Endosc 2007 Nov;21(11):1945–9.   [CrossRef]   [Pubmed]
