An internal hernia is a rare condition defined as the protrusion of abdominal viscera into one of the fossae, foramina, recesses, or congenital defects within the abdominal and pelvic cavity [1]. The sex ratio exposed a male prevalence of 3:2 [2]. The aperture can be normal, encased with a sac or either abnormal, not possessing a sac. Congenital anomalies due to improper intestinal rotation, previous trauma, vascular or inflammatory diseases, or postsurgical iatrogenic are predisposed factors to internal herniation. Internal hernias are generally classified into six types: paraduodenal, pericecal, foramen of Winslow, transmesenteric, pelvic and supravesical, and intersigmoid [2]. Internal hernias may present as intestinal obstruction and account for 0.5–4.1% of all cases [3]. Congenital and acquired defects in the mesentery of the cecum or appendix, may lead to development of a pericecal hernia. Anatomically, there are four types of peritoneal recesses of various sizes and depths identified in the pericecal region, including the superior ileocecal recess, inferior ileocecal recess, retrocecal recess and paracolic sulci [4] [5]. Internal abdominal hernias present a non-specific and intermittent clinical presentation. Therefore, clinical diagnosis of internal hernias is often difficult and thus imaging studies play an important role in the early diagnosis. Its diagnosis remains difficult even after the computed tomography (CT) scans disseminated accessibility and use. We present a case of atypical presentation of acute abdomen and was diagnosed as internal herniation with CT scan, thereafter confirmed with subsequent emergency surgery.

A 37-year-old female presented to the emergency department with diffuse abdominal pain, developing suddenly an hour ago. The pain was severe, not colicky and radiated through to her back. Sitting upright and leaning forward relieved the pain. She was also complaining from nausea and vomiting. She was passing flatus. Before, she had not experienced any similar pain. Her vital signs were normal. In her physical examination, there was diffuse tenderness, and rebound, guarding in right upper and lower quadrants. In blood gas analysis, her venous blood pH: 7.19, HCO₃: 16 mmol/L, CO₂: 47 mmHg, lactate 4.2 mmol/L, base excess: 10.6 mmol/L. In her total blood count, white blood cell was 13400/L. Her liver function tests were minimally elevated. As her pain was persistent and unexplained. A computed tomography scan of the abdomen and pelvis with intravenous contrast demonstrated dilatation and left migration of the loops of jejenum, migration of inferior mesenteric vein to the left, and free fluid in abdomen (Figure 1) and (Figure 2). With the prediagnosis of internal herniation, fluid resuscitation and supportive care were initiated for preparation for surgery. In the first, operation laparotomy with mid line incision made, 500 cc fluid was aspirated, it was seen that 50 cm segment of the terminal ileum was herniated medial to cecum (paracecal hernia), ileum was extracted from the defect. It was seen that loops of jejenum and terminal ileum up to 50 cm proximal to ileocecal valve were dilated and viable. Hot compresses were situated. Resection was not applied due to revascularization of ischemic loops was seen after 10 minutes. The defect was repaired and operation was terminated. After three days, patient deteriorated; in the exploration ischemia was detected beginning from 10 cm proximal of terminal ileum up to the 200 cm ileum. Ischemic loops were dissected, serosal tearing in ileum and sigmoid colon repaired. Efferent and afferent tips together subtracted from right upper quadrant. After four days, probably from micro perforations and ventilator associated pneumonia, in blood culture first methicillin resistant Staphylococcus auerus then Pseudomonas aeruginosa proliferated, despite of full septic shock treatment (fluid therapy; vancomycin, clindamycin, gentamycin antibiotic therapy; vasopressors with noradrenalin and dopamine), the patient died in intensive care unit due to sepsis and multi-organ failure.

In autopsies, internal hernia has been reported to range from 0.2–0.9% [2]. In the reality, we know that 5.8% cases of small bowel obstruction are due to internal hernia [4]. Internal herniation should be considered as a differential diagnosis in patients presenting with symptoms of small bowel obstruction without a history of prior abdominal surgery. Normally, standard hernias results from defects in the retaining walls of the abdomen. But internal hernias are due to the organ protrusion through an opening or pouch of the peritoneum. Patient may be asymptomatic or may have ileus symptoms and findings like constant epigastric pain or intermittent colicky periumbilical pain. There may be nausea or vomiting. The severity of the pain is related to the presence of ischemia or necrosis. As no specific symptoms are associated with the condition, it is rarely diagnosed preoperatively. Clinical examination is non-specific and laboratory findings are rarely helpful. Although the occurrence is rare, delayed diagnosis and treatment are associated with a high mortality rate. Abdominal CT scan is important for intestinal obstruction [6]. Computed tomography scan gives information about location of obstruction, the possible underlying causes, such as malignancy, stenosis within the bowel wall, and other intraluminal problems such as intussusception, feces or or Bezoar like substances [7]. Computed tomography scan has become the first-line imaging technique in patients with suspected acute abdomen. Etiologies of acute abdomen like internal hernias are often difficult to identify with physical examination [8]. Computed tomography scan showed classic signs of internal herniation as 'Whirlpool sign', crowding of bowel loops in the upper compartment and the absence of cecum in the right iliac fossa, replacement of abdominal organs and vasculature. If strangulation of the intestine is suspected including other causes also, an internal hernia should be considered as in our case. Delay in diagnosis and treatment is often observed in internal hernia cases and results high mortality rate of up to 49% [9]. In the operation, often intestinal obstruction associated with non-viable bowel detected. So the treatment invariably requires urgent surgery. Usually, open surgery is performed. Only a few cases of laparoscopic hernia management have been reported [10] . If there is intestinal necrosis, an adequate resection is mandatory. Nevertheless, there is no clear and established consensus on surgical management when the herniated contents are grossly viable.

In the symptoms of intestinal obstruction, a high index of suspicion for internal hernia is necessary to prevent diagnostic delay and mortality in emergency departments.

1. Rivkind AI, Shiloni E, Muggia-Sullam M, Weiss Y, Lax E, Freund HR. Paracecal hernia: A cause of intestinal obstruction. Dis Colon Rectum 1986 Nov;29(11):752–4.   [CrossRef]   [Pubmed]
2. Crispín-Trebejo B, Robles-Cuadros MC, Orendo-Velásquez E, Andrade FP. Internal abdominal hernia: Intestinal obstruction due to transmesenteric hernia containing transverse colon. Int J Surg Case Rep 2014;5(7):396–8.   [CrossRef]   [Pubmed]
3. Murali Appavoo Reddy UD, Dev B, Santosham R. Internal hernias: Surgeons dilemma-unravelled by imaging. Indian J Surg 2014 Aug;76(4):323–8.   [CrossRef]   [Pubmed]
4. Takeda M, Ohnuki Y, Uchiyama T, Kubota O, Ohishi K. Small intestinal strangulation due to a rare type of primary internal hernia. Int Surg 2013 Oct-Dec;98(4):409–11.   [CrossRef]   [Pubmed]
5. Selçuk D, Kantarci F, Ogüt G, Korman U. Radiological evaluation of internal abdominal hernias. Turk J Gastroenterol 2005 Jun;16(2):57–64.   [Pubmed]
6. Martin LC, Merkle EM, Thompson WM. Review of internal hernias: Radiographic and clinical findings. AJR Am J Roentgenol 2006 Mar;186(3):703–17.   [CrossRef]   [Pubmed]
7. Li B, Assaf A, Gong YG, Feng LZ, Zheng XY, Wu CN. Transmesosigmoid hernia: Case report and review of literature. World J Gastroenterol 2014 May 21;20(19):5924–9.   [CrossRef]   [Pubmed]
8. Kundaragi NG, Vinayagam S, Mudali S. Stretched bowel sign in combined transmesocolic and transomental internal hernia: A casereport and review of literature. Indian J Radiol Imaging 2014 Apr;24(2):171–4.   [CrossRef]   [Pubmed]
9. Sikiminywa-Kambale P, Anaye A, Roulet D, Pezzetta E. Internal hernia through the foramen of Winslow: A diagnosis to consider in moderateepigastric pain. J Surg Case Rep 2014 Jun 25;(6).   [CrossRef]   [Pubmed]
10. Farthouat P, Platel JP, Meusnier F, Salle E, Pourriére M, Thouard H. Winslow's foramen hernia. Preoperative computed tomographic diagnosis and laparoscopic treatment. Ann Chir 1998;52(4):387–9. [Article in French].   [Pubmed]
