Pretibial myxedema (PTM) is an immune mediated localized form of thyroid associated dermopathy often found in patients with autoimmune thyroid disease, particularly Graves’ diseases. [1] Rarely, it is also seen in patients with hypothyroidism. [2] The skin lesions are diffuse, non-pitting in majority. However, plaques and nodular forms have also been describe in literature. Elephantiasis form of (PTM) which is known as elephantiasis nostra verrucosa (ENV) is extreme rare form which is found late in the course of Graves’ disease. [3] We describe a case who remained hypothyroid for a long period of time, eventually developed elephantiasic PTM.

A 45-year-old male presented with large irregular nodular swelling over anterior aspects of tibia bilaterally. These swellings were gradually increasing in size for past two years. He had a history of thyroidectomy for large toxic goitre seven years back in an outside hospital. He was not on thyroxin replacement therapy and was never on follow-up. He neither lived nor had any visit to filarial endemic area. On examination, he had dry skin, sallow complexion and periorbital puffiness. (Figure 1A) He also had grade 3 clubbing of fingers. (Figure 1B) The bilateral firm confluent pretibial polypoid nodular lesions were hyperpigmented, firm, asymmetric and non-pitting and there were plaques between and over the nodules. (Figure 1C) His pulse was 64 per minute and regular rhythm and blood pressure was 130/84 mmHg. The thyroid function test revealed severe hypothyroidism, his TSH level was more than 100 mIU/mL (normal limit 0.4–4.4 mIU/mL). Blood examination did not reveal the presence of filarial parasite and furthermore, filarial antigen and antibody tests were negative. Thyroid stimulating receptor antibody titer was 40IU/L (normal limits <1.5 IU/L). Biopsy of one of the nodular skin lesions revealed separation of collagen fibers, extensive deposition and stellate fibroblasts consistent with the findings of pretibial myxedema. (Figure 2) He was started with 125 µg/day of thyroxine and steroid ointment with tight occlusive bandage for pretibial swelling. After three months of therapy, there was regression of symptoms of hypothyroidism and modest decrease in nodular pretibial myxedema. Currently, he is planned for intralesional glucocorticoids.

Pretibial myxedema is an infrequent manifestation of autoimmune thyroid disease as a result of immune mediated phenomenon. [1] About 0.5–4.3% of patients with a history of thyrotoxicosis have thyroid dermopathy, and 15% of patients with severe Graves’ ophthalmopathy have this cutaneous manifestation. [4] According to one study, PTM was also found with frequency of 17.1% in Hashimoto’s thyroiditis, and 6.5% in idiopathic hypothyroidism. [5] The elephantiasic pretibial myxedema constitutes less than 1% of PTM. Our patient had toxic nodular goitre and underwent thyroidectomy, subsequent hypothyroidism and eventually developed PTM.

Classically, histopathology of these lesions shows increase in levels of glycosaminoglycan (GAG) in the reticular dermis with excess increase in hyaluronic acid concentration. [6] The proposed mechanism for this is thought to be due to fibroblast stimulation by thyroid-stimulating hormone receptor (TSH-R) antibodies. [6] [7] Histopathological findings in our case is same as describe in literature and the level of TSH-R stimulating antibodies was also elevated suggesting the role of TSH-R stimulating antibodies in fibroblast proliferation and synthesis of GAG.

The most commonly describe therapy for PTM is tight occlusive steroid dressing [6] which has also been given in our case. The response rate varies with topical steroid occlusive dressing is 26-50%. Our case responded dramatically with local steroid as well as thyroxine replacement.

We are grateful to Department of Photography (Mr. Brij Lal and Mr. Abijeet) for the taking patient photographs. We also thank Mr. Prakamya Gupta for manuscript editing.

Elephantiasic pretibial myxedema is a rare disease. This condition should be recognized promptly and should be treated with steroid occlusive dressing and treatment of underlying thyroid disease.
