Most of the humeral fractures heal uneventfully with conservative methods. Although the operative treatment of fractures has improved the care of many patients, it may also produce undesirable consequences. Loss of fixation and non-union are two major complications of humeral fractures treated with open reduction and plate fixation.

Non-union rates of humeral shaft fractures are reported 10–15% with surgical treatment methods. [1] [2] Open fractures, segmental fractures, highly comminuted fractures, transvers fractures and impaired host healing (diabetes, smoking and malnutrition) are the basic risk factors of humerus shaft non-union. If a humeral shaft non-union is diagnosed, conservative treatment methods are not recommended because of poor results reported. [3] If previous surgery has been performed hardware removal, debriding the fibrous tissue, bone grafting and fixation should be done to achieve a solid union. External fixation should be necessary in cases of infected non-unions where internal devices are not useful for fixation.

Loss of fixation is the result of inadequate surgical technique. To achieve stability with plate osteosynthesis, the plate must have adequate thickness and length. By compression plating at least four screws holes must overlie each major distal end proximal fragments and equal length of plate and number of screws should be on both sides of fracture. [4] Obvious loss of stability on radiographs or clinical examination is a clear evidence of non-union and should be re-evaluated for revision surgery. We would like to present a case where a humeral shaft fracture treated with inadequate plating technique resulted with loss of fixation and treated with close manipulation and bracing without hardware removal.

A 28-year-old male diagnosed with closed humerus shaft fracture due traffic accident without neurovascular injury. He was treated with open reduction and plate fixation at another hospital four months ago. (Figure 1A-B) Postoperative period was uneventful. However, there was a lack of union after 12 weeks. (Figure 2) He was presented to our outpatient clinic with severe pain after a minor trauma. The plain radiographs revealed a non-union of humerus shaft fracture with loss of reduction and implant failure with a broken screw. (Figure 3) There was no evidence of infection on clinical examination and C-reactive protein level was also normal. The patient was diagnosed with atrophic non-union with implant failure and offered revision surgery with implant removal, bone grafting and fixation with a longer and thicker plate. However, the patient did not accept revision surgery demanded conservative treatment. Closed manipulation (Figure 4A-B) under sedation and a Sarmiento type brace cast was applied. Although the reduction was good, the patient was informed of high risk of ineffectiveness of this treatment method. During monthly follow-up, there was no loss of reduction again, and at the fourth month follow-up after closed manipulation solid bony union was achieved without any deformity. (Figure 5A-B)

Humerus non-unions can be severely disabling and the treatment should be different then acute fracture treatment. Although many authors suggested debridement, open reduction and plate fixation for non-unions of the humeral shaft inadequate plating technique is the main reason of failure. [5] [6] In order to have enough stability at the non-union site, double plating, one on the lateral side and one on the posterior side is recommended. [7] Bone grafting is offered to enhance the biological environment. [8]

Functional bracing for the humeral shaft provides high union rates but it is not the recommended treatment option for humeral diaphyseal non-unions. On elderly patients with low demands functional bracing could be considered as an option to support the limb but on active young patient bony union must be achieved in order to restore function. [9] We could not find any paper in literature about the treatment of previously surgically intervened humerus diaphyseal non-union with implant failure treated with closed reduction and functional bracing.

The case of our patient illustrates that functional bracing can be appropriate for humerus diaphyseal non-unions with implant failure when the patient is not suitable for surgery.

1. Sarmiento A, Zagorski JB, Zych GA, Latta LL, Capps CA. Functional bracing for the treatment of fractures of the humeral diaphysis. J Bone Joint Surg Am 2000;82(4):478–6.   [Pubmed]
2. Marti RK, Verheyen CC, Besselaar PP. Humeral shaft nonunion: evaluation of uniform surgical repair in fifty-one patients. J Orthop Trauma 2002;16(2):108–15.   [CrossRef]   [Pubmed]
3. Anglen JO. Enhancement of fracture healing with bone stimulators. Failed internal fixation. Tech Orthop 2002;17:506–14.   [CrossRef]
4. Anglen JO, Archdeacon MT, Cannada LK, Herscovici D Jr, Ostrum RF. Avoiding complications in the teratment of humeral fractures. Instr Course Lect 2009;58:3–11.   [Pubmed]
5. Ring D, Perey BH, Jupiter JB. The functional outcome of operative treatment of ununited fractures of the humeral diaphysis in older patients. J Bone Joint Surg Am 1999;81(2):177–90.   [Pubmed]
6. Foster RJ, Dixon GL Jr, Bach AW, Appleyard RW, Green TM. Internal fixation of fractures and non-unions of the humeral shaft. Indications and results in a multi-center study. J Bone Joint Surg Am 1985;67(6):857–64.   [Pubmed]
7. Murray WR, Lucas DB, Inman VT. Treatment of non-union of fractures of the long bones by the two-plate method. J Bone Joint Surg Am 1964;46:1027–48.   [Pubmed]
8. Hierholzer C, Sama D, Toro JB, Peterson M, Helfet DL. Plate fixation of ununited humeral shaft fractures: effect of type of bone graft on healing. J Bone Joint Surg Am 2006;88(7):1442–7.   [CrossRef]   [Pubmed]
9. Rosen, H. Management of nonunions and malunions in long bone fractures. In Comprehensive Care of Orthopaedic Injuries in the Elderly, pp. 489–511. Edited by J. D. Zuckerman. Baltimore, Urban and Schwarzenberg, 1990.
