Case Report

An unusual cause of acute carpal tunnel syndrome: An undetected foreign body
Hakan Tekin1, Ömer Faruk Koçak2, Şafak Aktar3
1MD, Van Regional Training and Research Hospital, Plastic Reconstructive and Aesthetic Surgery Department.
2MD, Yuzuncu Yil University, Plastic Reconstructive and Aesthetic Surgery Department.
3MD, Malatya State Hospital, Plastic Reconstructive and Aesthetic Surgery Department.

doi:10.5348/ijcri-201606-CR-10593

Address correspondence to:
Hakan Tekin
Van Regional Training and Research Hospital
Plastic Reconstructive and Aesthetic, Surgery Clinic
Edremit, Van
Turkey

Access full text article on other devices

  Access PDF of article on other devices

[HTML Abstract]   [PDF Full Text] [Print This Article]
[Similar article in Pumed] [Similar article in Google Scholar]


How to cite this article
Tekin H, Koçak ÖF, Aktar S. An unusual cause of acute carpal tunnel syndrome: An undetected foreign body. Int J Case Rep Images 2016;7(1):30–33.


Abstract
Introduction: Carpal tunnel syndrome (CTS) is a trap neuropathy in which the median nerve is entrapped and compressed. Various factors have been implicated in its etiology and to date no single cause has been identified. In literature, foreign bodies following trauma have been rarely reported to compress the median nerve, resulting in CTS.
Case Report: A 19-year-old male patient presented to our outpatient clinics due to symptoms of CTS. The patient had a history of hand injury with window glass. The patient was examined both in emergency department and then in family health center. In examination with palpation and X-ray graphics an undetected foreign body was found.
Conclusion: The current report presents a case of an undetected foreign body that resulted in acute carpal tunnel syndrome, and which could be the subject of a medical malpractice lawsuit.

Keywords: Carpal tunnel syndrome, Foreign body, Malpractice, Median nerve


Introduction

Carpal tunnel syndrome (CTS) is a trap neuropathy in which the median nerve is compressed as it travels through the carpal tunnel. Sir James Paget first described the condition in 1865 [1]. Clinically, the condition presents as pain, numbness, burning, tingling and stinging pain in the thumb and index finger as well as the radial aspect of the middle and ring fingers [2]. Obesity, rheumatoid arthritis, steroid use, pregnancy, female gender, diabetes mellitus, acromegaly, hyperparathyroidism, patent median artery have been reported as risk factors in its etiology [3] [4][5]. Uncommon causes, such as benign and malignant tumors, anatomic variations, vascular insufficiency, trauma, and foreign body have also been reported in literature [6] [7] [8]. However, the condition is most frequently idiopathic [6]. In addition to high treatment costs and loss of labor, CTS can also cause permanent disability [9]. Acute carpal tunnel syndrome (ACTS) is different from classic CTS. ACTS is more rare entity according to CTS and mostly occurs after upper extremity traumas [10]. In literature, very rare cases of ACTS have been reported in association with unnoticed foreign body that remained in the median nerve following hand trauma [6] [7]. The current report presents a case of a penetrating foreign body that caused ACTS without causing median nerve injury.


Case Report

A 19-year-old male patient presented to our outpatient clinics due to pain, burning, numbness, and tingling in the right thumb and index finger and a feeling of solid mass in the palms for the previous three weeks. During an argument with friends and the illicit use of drugs, the patient had hit a window with his hand.

Following the incident, the patient was taken to the emergency room where his hand movements had been examined. All finger movements were found to be normal and the patient denied any numbness in his fingers. A small skin incision on his wrist sutured, antibiotics and analgesics were prescribed and the patient was discharged from the hospital. The patient's complaint started 6–7 days after the injury and he presented to the family physician. After obtaining the patient's history, the family physician has referred the patients to our outpatient clinics with the pre-diagnosis of CTS. The patient did not undergo a radiological evaluation either in the emergency room or the family health center. On physical examination, there was a 1.5-cm long immature scar on the proximal crease on the volar aspect of the wrist. There was tenderness and pain on palpation of the palm. A hard, mobile object on the palm surface at the level of the proximal crease was palpated (Figure 1). An X-ray examination disclosed a semi-opaque foreign body (Figure 2). The patient was operated under regional nerve block. A glass fragment measuring 6.5 x1.5 cm was located beneath the flexor retinaculum and passing over the median nerve, which had compressed and flattened (Figure 3) and (Figure 4) the median nerve. The fragment was removed without any damage to the median nerve. No complications occurred in post-operation period. The patient's compliant diminished over a two weeks period. After three weeks, the patient dropped out from follow-up.


Cursor on image to zoom/Click text to open image
Figure 1: Localization of foreign body by palpation.



Cursor on image to zoom/Click text to open image
Figure 2: Foreign body on X-ray.



Cursor on image to zoom/Click text to open image
Figure 3: The glass piece in carpal tunnel.



Cursor on image to zoom/Click text to open image
Figure 4: Formation of fibrosis. Median nerve was just under the thin fibrotic tissue.



Discussion

Carpal tunne syndrome is a progressive neuropathy often characterized by a chronic course with the gradual loss of hand functions [11]. In the case of acute ACTS occurring within a short period of time, as little as a couple of days, mass lesions, foreign body or hematoma, which mechanically compresses the median nerve, should be suspected [12]. In particular, a history of trauma and previous surgery should be questioned. Although classic CTS develops in weeks or months the ACTS develops more rapidly and symptoms occur within days [13]. In ACTS, pressure in the carpal tunnel elevates due to mass effect, but in CTS there is a chronic inflammatory process rather than acute mass effect [14]. Classic CTS is not-common in young patient [11]. In this case, the patient's complaints were started 6–7 days after injury. The young patient who is a drug abuser, waited for spontaneous resolution of symptoms. For diagnosis of post-traumatic ACTS, examination with palpation and radiological investigation are needed. This case was considered as ACTS due to history of hand trauma, patient's age and rapid onset of symptoms. ACTS must be treated rapidly to avoid any motor dysfunction [10].

Hand injuries comprise the most frequent cases presenting to the emergency rooms and most are associated with foreign body penetration [15]. Even though finger movement, circulation, and sensation are found normal on physical examination, manual examination (palpation) and a radiological evaluation must definitely be performed. Standard physical examination may miss up to 38% of foreign bodies [16]. Thus, the appropriate radiological imaging method must be made if any suspicion of an impaled foreign body persists. A simple X-ray examination is the first option for radiopaque objects [17]. However, ultrasonography may be the first choice for investigating non-radiolucent objects and computed tomography scan may be the first choice for complex injuries [18]. It should be kept in mind that foreign bodies left in the hand and the resulting complications are one of the major causes of malpractice lawsuits [19] [20]. This foreign body that remained undetected in the carpal tunnel and resulted in CTS is the largest foreign body reported to date in literature.


Conclusion

The aim of this case report is to highlight the fact that foreign bodies penetrating the hand may be missed on a classical physical examination, particularly in substance abusers, and these objects may result in permanent consequences in the long-term. We suggest that performing a thorough manual examination, as well as obtaining an X-ray, would prevent such an undesired malpractice, and one that could be the subject of lawsuits for physicians in the emergency room.


References
  1. Phalen GS. The carpal-tunnel syndrome. Seventeen years' experience in diagnosis and treatment of six hundred fifty-four hands. J Bone Joint Surg Am 1966 Mar;48(2):211–28.   [CrossRef]   [Pubmed]    Back to citation no. 1
  2. Dawson DM. Entrapment neuropathies of the upper extremities. N Engl J Med 1993 Dec 30;329(27):2013–8.   [CrossRef]   [Pubmed]    Back to citation no. 2
  3. de Krom MC, Kester AD, Knipschild PG, Spaans F. Risk factors for carpal tunnel syndrome. Am J Epidemiol 1990 Dec;132(6):1102–10.   [Pubmed]    Back to citation no. 3
  4. Stevens JC, Beard CM, O'Fallon WM, Kurland LT. Conditions associated with carpal tunnel syndrome. Mayo Clin Proc 1992 Jun;6(12)60461–3.   [CrossRef]   [Pubmed]    Back to citation no. 4
  5. Lavey EB, Pearl RM. Patent median artery as a cause of carpal tunnel syndrome. Ann Plast Surg 1981 Sep;7(3):236–8.   [CrossRef]   [Pubmed]    Back to citation no. 5
  6. Robinson AJ, Basheer MH, Herbert K. An unusual cause of carpal tunnel syndrome. J Plast Reconstr Aesthet Surg 2010 Nov;63(11):e788–91.   [CrossRef]   [Pubmed]    Back to citation no. 6
  7. Sadat-Ali M, Bluwi M. Unusual cause of carpal tunnel syndrome: a case report. Hand Surg 2004 Jul;9(1):115–6.   [CrossRef]   [Pubmed]    Back to citation no. 7
  8. Pfeffer GB, Gelberman RH, Boyes JH, Rydevik B. The history of carpal tunnel syndrome. J Hand Surg Br 1988 Feb;13(1):28–34.   [Pubmed]    Back to citation no. 8
  9. Foley M, Silverstein B, Polissar N. The economic burden of carpal tunnel syndrome: long-term earnings of CTS claimants in Washington State. Am J Ind Med 2007 Mar;50(3):155–72.   [CrossRef]   [Pubmed]    Back to citation no. 9
  10. Bauman TD, Gelberman RH, Mubarak SJ, Garfin SR. The acute carpal tunnel syndrome. Clin Orthop Relat Res 1981 May;(156):151–6.   [CrossRef]   [Pubmed]    Back to citation no. 10
  11. Becker J, Scalco RS, Pietroski F, Celli LF, Gomes I. Is carpal tunnel syndrome a slow, chronic, progressive nerve entrapment? Clin NeurClin Neurophysiol 2014 Mar;125(3):642–6.   [CrossRef]   [Pubmed]    Back to citation no. 11
  12. Shimizu A, Ikeda M, Kobayashi Y, Saito I, Oka Y. Carpal tunnel syndrome caused by a ganglion in the carpal tunnel with an atypical type of palsy: a case report. Hand Surg 2011;16(3):339–41.   [CrossRef]   [Pubmed]    Back to citation no. 12
  13. McClain EJ, Wissinger HA. The acute carpal tunnel syndrome: nine case reports. J Trauma 1976 Jan;16(1):75–8.   [CrossRef]   [Pubmed]    Back to citation no. 13
  14. damson JE, Srouji SJ, Horton CE, Mladick RA. The acute carpal tunnel syndrome. Plast Reconstr Surg 1971 Apr;47(4):332–6.   [CrossRef]   [Pubmed]    Back to citation no. 14
  15. Frazier WH, Miller M, Fox RS, Brand D, Finseth F. Hand injuries: incidence and epidemiology in an emergency service. JACEP 1978 Jul;7(7):265–8.   [CrossRef]   [Pubmed]    Back to citation no. 15
  16. Anderson MA, Newmeyer WL 3rd, Kilgore ES Jr. Diagnosis and treatment of retained foreign bodies in the hand. Am J Surg 1982 Jul;144(1):63–7.   [CrossRef]   [Pubmed]    Back to citation no. 16
  17. Donaldson JS. Radiographic imaging of foreign bodies in the hand. Hand Clin 1991 Feb;7(1):125–34.   [Pubmed]    Back to citation no. 17
  18. Manthey DE, Storrow AB, Milbourn JM, Wagner BJ. Ultrasound versus radiography in the detection of soft-tissue foreign bodies. Ann Emerg Med 1996 Jul;28(1):7–9.   [CrossRef]   [Pubmed]    Back to citation no. 18
  19. Dunn JD. Risk management in emergency medicine. Emerg Med Clin North Am 1987 Feb;5(1):51–69.   [Pubmed]    Back to citation no. 19
  20. Vukmir RB. Medical malpractice: managing the risk. Med Law 2004;23(3):495–513.   [Pubmed]    Back to citation no. 20
