Case Report

Sirenomelia: A case report
Swagat Mahapatra1, Suruchi Ambasta2
1MS, Orthopedics, Senior Resident, Department of Orthopedics, JIPMER, Pondicherry, India.
2MD Anesthesiology, Senior Resident, Department of Anesthesiology and Critical Care, JIPMER, Pondicherry, India.

doi:10.5348/ijcri-2014113-CR-10424

Address correspondence to:
Swagat Mahapatra
Old MSR Quarters No-21, Dhanawantary Nagar
JIPMER Campus, Puducherry
Pondicherry
India - 605006
Phone: +918940482218
Email: drswagat@gmail.com

Access full text article on other devices

  Access PDF of article on other devices

[HTML Abstract]   [PDF Full Text] [Print This Article]
[Similar article in Pumed] [Similar article in Google Scholar]


How to cite this article
Mahapatra S, Ambasta S. Sirenomelia: A case report. Int J Case Rep Images 2014;5(9):638–641.


Abstract
Introduction: Sirenomelia is a congenital structural anomaly characterized by abnormal development of the caudal region of the body with varying degrees of fusion of lower limbs. Most of the times, the condition is fatal for the baby. Most babies do not survive even after surgery. Fifty percent of cases are seen as stillbirths, and it is much more common in identical twins. This abnormality was initially confused with caudal regression syndrome, but later was given a new name, i.e., sirenomelia mermaid syndrome.
Case Report: We present a case of a 15-year-old boy with partially fused lower limbs. A provisional diagnosis of sirenomelia is made and detailed review and surgery was planned. The boy did not report for further treatment.
Conclusion: Very rare disorder with prevalence of 1 in 100,000 live births with a total of 300 cases reported till today in which nine are from India. The precise etiology of sirenomelia was not well understood. Many theories have been proposed but none of these is considered definitive. It is very important to diagnose this condition by ultrasonography so that termination of pregnancy can be carried out.

Keywords: Sirenomelia, Caudal regression syndrome, Deformity, Congenital structural anomaly, Fusion


Introduction

Sirenomelia is a congenital structural anomaly characterized by abnormal development of the caudal region of the body with varying degrees of fusion of lower limbs. Almost always the condition proves fatal for the baby. Most babies do not survive even after surgery. Fifty percent of cases are seen as stillbirths, and it is much more common in identical twins. After initial confusion with caudal regression syndrome, it was later given a new name-sirenomelia mermaid syndrome. Sirenomelia is characterized by complete fusion of bilateral lower limbs, along with renal agenesis, gastrointestinal defects and absent external genitalia. An important finding which differentiates these two entities is the presence of single umbilical and persistent vitelline artery.


Case Report

A 15-year-old boy presented to our outpatient department with deformity of both lower limbs with partial fusion of lower legs since birth. He was accompanied by his parents. On taking detailed history, it was found that parents had not ever consulted any doctor. Patient was able to ambulate independently with a single stick. He was not having any other complaint as such and was mentally normal. He was having no other physical anomalies in the skull, facies, chest and lumbar region. On examination of both the lower limbs, it was seen that pelvis and both femur were normal. The left popliteal fossa was at a lower level than the right. Fusion of the lower limbs was noted at the level of distal one-third of the leg about 8 cm above bilateral ankle joint. Below the level of fusion the right distal leg was straight but the left distal leg and ankle foot complex was deviated laterally with acute angulation. Both feet were maldeveloped with rockerbottom deformity with the absence of great toe on the left foot and few other phalanges in both feet (Figure 1) and (Figure 2). On palpation, it was felt that the proximal part of the left tibia was fused with the right tibia. X-rays confirmed our findings of fusion of bilateral tibia with acute angulation of the left tibia with partial absence of metatarsals and phalanges (Figure 3). The development of feet above the level of fusion was adequate but below this level both feet were maldeveloped. A provisional diagnosis of sirenomelia was made and further workup and plan for surgery was made. The parents agreed for workup and left to come prepared for admission but they did not come for admission and also did not respond to repeated calls.


Cursor on image to zoom/Click text to open image
Figure 1: Clinical photograph of both lower limbs showing fusion of lower leg with both ill formed feet.



Cursor on image to zoom/Click text to open image
Figure 2: Clinical photograph of both feet with legs showing standing attitude with left popliteal fossa at a lower level than right.



Cursor on image to zoom/Click text to open image
Figure 3: X-ray features of both lower limbs showing fusion of distal part of left tibia with the right with lateral bending of left leg.



Discussion

A mermaid is a legendary aquatic creature with the upper body of a female human and the tail of a fish. Mermaids are associated with the biological order sirenia comprising dugongs and manatees. Hence this syndrome is named sirenomelia. Sirenomelia is a congenital structural anomaly characterized by abnormal development of the caudal region of the body with varying degrees of fusion of lower limbs [1]. It bears the resemblance of Mermaid of Greek mythology and hence the synonym of Mermaid syndrome [2]. The prevalence of this anomaly is 1:100.000 live births with a male to female ratio of 3:1. About 300 cases are reported in which nine are from India [3].

There are clinically mild and severe varieties. In mild variety, the sirenomelia baby has two limbs fused into one, only to the extent of the skin. The feet may be fully formed and many are only attached at the ankles. All the three main bones of the leg are fully and correctly formed. In this situation, a small surgery can easily correct the deformity whereas the severe variety is very difficult to manage. Externally both limbs are completely joined and appear ill-formed. There is a complete absence of foot structures and out of the three long bones, only two are present in the entire limb. Other internal abnormalities can only be accessed with imaging studies. Distinction was made between these due to the fact that the sirenomelia had a specific pathogenic factor namely arterial steal phenomenon. On the other hand, the caudal regression syndrome was probably due to diabetic embryopathy. An important finding which differentiates these two entities is presence of single umbilical and persistent vitelline artery. Sirenomelia has also been classified into three types simpus apus (no feet, one tibia, one femur), simpus unipus (one foot, two femur, two tibia, two fibula), simpus dipus (two feet and two fused legs (flipper like)-this is called a mermaid). The first case of sirenomelia was seen in 1542. Duhamel gave the term caudal regression syndrome in 1961 in which he described that sirenomelia was associated with anorectal, genitourinary and vertebral anomalies.

The precise etiology of sirenomelia is not well understood. Many theories have been proposed but none of these is considered conclusive. Hibelink et al. [4] told IV cadmium and lead can produce sirenomelia in the golden hamster. Von Lennep et al. [5] stated teratogenic effects of Vitamin A, Duhemmel et al. [6] told manifestation of the caudal regression syndrome. Quan et al. [7] coined the term VATER, Stocker et al. [8] proposed defect in the primitive streak, Stevenson [9] explained vitelline artery steal theory.

Ultrasonography of a fetus with sirenomelia demonstrates the fused femur, decreased distance between two femurs and decreased or absent mobility of the two lower limbs with respect to each other. When infant is clinically examined, there may be only simple fusion of skin of the limbs or there may be fusion of all long bones except fused femur. So imaging studies such as X-rays which show the bony abnormalities and ultrasonography are advised to see for solid organ abnormality. This disorder is universally lethal and hence prenatal diagnosis with imaging studies is very helpful to plan termination of pregnancy [10] [11].


Conclusion

In our case, we could not find many of the features as described for this rare condition. Also we could not further investigate to clinch the etiology due to non-cooperation of the patient. This rare abnormality is usually universally fatal but this boy was found to be healthy at fifteen years of age. This case was reported due its rarity.


References
  1. Jones KL. Sirenomelia sequence in smith's recognizable patterns of humal malformation. WB saunders company, Philadelphia 1998:634.    Back to citation no. 1
  2. De Silva MV, Lakshman WD. Sirenomelia sequence (Mermaid syndrome). Ceylon Med J 1999;44(1):34–5.   [Pubmed]    Back to citation no. 2
  3. Parthasarathy S. Shivanarutselvan - Sirenomelia - A case report-Interesting cases in orthopaedics. IJCP;2:23–5.    Back to citation no. 3
  4. Hilbelink DR, Kaplan S. Sirenomelia: Analysis in the cadmium and lead treated golden hamster. Teratog Carcinog Mutagen 1986;6(5):431–40.   [CrossRef]   [Pubmed]    Back to citation no. 4
  5. Von Lennep E, El Khazen N, De Pierreux G, Amy JJ, Rodesch F, Van Regemorter N. A case of partial Sirenomelia and possible vitamin A teratogenesis. Prenat Diagn 1985;5(1):35–40.   [CrossRef]   [Pubmed]    Back to citation no. 5
  6. Duhamel B. From the mermaid to anal imperforation: The syndrome of caudal regression. Arch Dis Child 1961;36(186):152–5.   [CrossRef]   [Pubmed]    Back to citation no. 6
  7. Quan L, Smith DW. The VATER association. Vertebral defects, anal atresia, tracheo-esophageal fistula with esophageal atresia, renal and radial dysplasia: A spectrum of associated defects. J Pediatr 1973;82(1):104–7.   [Pubmed]    Back to citation no. 7
  8. Stocker JT, Heifetz SA. Sirenomelia. A morphological study of 33 cases and review of the literature. Perspect Pediatr Pathol 1987;10:7–50.   [Pubmed]    Back to citation no. 8
  9. Stevenson RE, Jones KL, Phelan MC, et al. Vascular steal: The pathogenetic mechanism producing sirenomelia and associated defects of the viscera and soft tissues. Pediatrics 1986;78(3):451–7.   [Pubmed]    Back to citation no. 9
  10. Duncan PA, Shapiro LR, Klien RM. Sacrococcygeal dysgenesis association. Am J Med Genet 1991;41(2):153–61.   [CrossRef]   [Pubmed]    Back to citation no. 10
  11. Schuler L, Salzano FM. Patterns in multimalformed babies and the question of relationship between sirenomelia and VACTERL. Am J Med Genet 1994;49(1):29–35.   [CrossRef]   [Pubmed]    Back to citation no. 11
