Case Report

Situs inversus and metastatic renal cell carcinoma: A case report
Sunil Rangarajan1, Bhuvana Sunil2, Arun S Shet3
1Junior Resident, Department of Medical Oncology, St. John's Medical College and Hospital, Bangalore, Karnataka, India.
2Research Associate, St. John's Research Institute, Bangalore, Karnataka, India.
3Professor & Head, Department of Medical Oncology, St. John's Medical College and Hospital, Bangalore, Karnataka, India.

doi:10.5348/ijcri-2012-11-208-CR-1

Address correspondence to:
Arun S Shet
Department of Medical Oncology, St. John's Medical College and Hospital
The St. John's National Academy of Health Sciences, Sarjapur Road
Bangalore 560034
India
Phone: 91-80-22065744
Fax: 91-80-25532037
Email: arunshet1@gmail.com

Access full text article on other devices

  Access PDF of article on other devices

[HTML Abstract]   [PDF Full Text] [Print This Article]
[Similar article in Pumed] [Similar article in Google Scholar]


How to cite this article:
Rangarajan S, Sunil B, Shet AS. Situs inversus and metastatic renal cell carcinoma: A case report. International Journal of Case Reports and Images 2012;3(11):1–4.


Abstract
Introduction: Situs Inversus Totalis is a rare congenital condition with an autosomal recessive inheritance. Most of the people with SIT are asymptomatic, making its diagnosis a challenge. Although many cases of cancers co-existing with SIT have been reported in medical literature, the co-existence of RCC with SIT is extremely rare. We are presenting the 5th reported case in the published medical literature.
Case Report: We report a case of a 65- year-old male who was presented with intractable back pain, difficulty in performing daily activities and unintentional weight loss. Evaluation of these symptoms revealed SIT, a right renal mass and widespread metastatic deposits. Immunohistochemical analysis confirmed the diagnosis of clear cell type of renal cell carcinoma.
Conclusion: Situs Inversus is a rare congenital abnormality which may be associated with renal anomalies, Kartagener syndrome, and several types of malignancies. Further study is needed to characterize the genetic basis of SI and establish whether there is a causal basis between SI and the development of malignancy or not.

Key Words: Situs inversus totalis, Renal cell carcinoma, Malignancy

Introduction

Situs inversus totalis (SIT) refers to a congenital condition in which the thoracic and the abdominal viscera are transposed through the sagittal plane. It is an autosomal recessive condition with 0.01–0.02% prevalence in general population [1]. Most of the people with SIT are asymptomatic, making its diagnosis a challenge. Among all diagnosed cancers, only 2–3% belong to renal cell carcinoma (RCC), which has a greater occurrence in males, [2]. Although many cases of cancers co-existing with SIT have been reported in medical literature, the co-existence of RCC with SIT is extremely rare. We are presenting a rare case of metastatic RCC with SIT, which is the 5th reported case in the published medical literature.


Case Report

A 65-year-old male was presented to the hospital with four months history of fatigue, difficulty in getting up, walking and performing daily activities. He had severe right flank and back pain, unintentional and significant weight loss of 12 kg. There were occasional episodes of fever and hematuria over this four-month period. A limited cut magnetic resonance imaging (MRI) of the spine and abdomen to evaluate the back pain revealed SIT, a right renal mass, and multiple osseous lesions in L1, and L2 vertebrae and in sacrum, (Figure 1). The patient admitted to a chronic history of tobacco (64 pack years of smoking) and alcohol consumption. On physical examination, the patient was cachectic (weight: 43 kg, height: 1.6 m, Body Mass Index: 16.8 kg/m2). Pertinent positive findings on systemic examination revealed findings of SIT in the chest and abdomen. Respiratory system examination revealed that the trachea was deviated to the right, and dull percussion sounds were noted in the right infra-axillary, infrascapular areas. Breath sounds and vocal resonance were diminished in the right mammary, infra-axillary, infrascapular areas and there were scattered occasional rhonchi. Apart from dextrocardia, the cardiac examination was unremarkable. Neurological examination revealed extreme tenderness on palpation over the L1, and L2 vertebrae, and mild weakness on the left half of the body.

Aside from hypoalbuminemia, and elevations in the ESR and LDH, the other hematological and biochemical parameters were normal. Of note, the serum calcium was normal. Urinalysis revealed hematuria but the sediment was otherwise normal. A contrast enhanced computerized axial tomogram (CAT) scan of the abdomen performed to evaluate the extent of the disease revealed abdominal viscera transposed through the sagittal plane, and an ill-defined right renal mass measuring 4x3.5 cm with multiple para aortic lymph nodes, and multiple vertebral deposits, (Figure 2). CAT scan of the thorax revealed dextrocardia, a 6.5x5 cm solitary irregular mass in the apicoposterior segment of the anatomical right lung engulfing the anatomical right pulmonary artery, mediastinal lymphadenopathy, and multiple rib deposits, (Figure 3). A bone scan was not performed as the patient declined further testing.

CAT scan guided tru-cut biopsy of the most accessible metastatic deposit in the sacrum revealed CAT scan guided tru-cut biopsy of the most accessible metastatic deposit in the sacrum revealed neoplastic cells arranged in a glandular pattern. Immunohistochemical analysis revealed the malignant cells to be positive for pancytokeratin (3+, 95%), cytokeratin (CK) 5 and CK 7 (3+, 95%), CD 10 and vimentin (3+, 100%), and negative for thyroid transcription factor-1 (TTF-1) and prostate-specific antigen (PSA) (Figure 4). Based on the clinical, radiological, and histopathological findings, a diagnosis of metastatic clear cell type of RCC was made and the patient was counseled regarding his disease [3]. The patient was offered palliative radiation therapy but elected to receive opioid analgesia as the sole pain control modality. Over the next few days his overall condition deteriorated and he elected to get discharged from the hospital for home hospice care.


Cursor on image to zoom/Click text to open image
Figure 1: MRI of the Spine, (A) Renal mass in the anatomical right kidney; (B) Multiple metastatic deposits in the vertebrae, largest being the one in the sacrum.



Cursor on image to zoom/Click text to open image
Figure 2: Contrast CT of Abdomen: (A) Mass in the anatomical right kidney with a metastatic lesion in the L1 vertebra; no extension of the mass into the renal vein. (B) Metastatic deposit in the sacrum.



Cursor on image to zoom/Click text to open image
Figure 3: (A): Contrast CT of the thorax and abdomen: Image reveals the mass in the anatomical right lung with mediastinal lymph node involvement. It also reveals situs inversus of the abdomen, (B): Contrast CT of Thorax: Mass in the anatomical right lung engulfing the right division of the Pulmonary Artery. The inversion of the location of the great vessels showing Situs Inversus in the thoracic viscera.



Cursor on image to zoom/Click text to open image
Figure 4: (A) Hematoxylin and Eosin staining of the biopsy tissue revealing the presence of thick fibrocollagenous tissue with an infiltrating neoplasm composed of neoplastic cells arranged in glandular pattern, (B) CD 10 staining positive, (C) Vimentin staining positive, and (D) CK 7 staining positive.



Discussion

Situs inversus (SI) is a rare disorder where most patients are asymptomatic leading to difficulty in assessing its true prevalence. It can be broadly classified based on the extent of the inversion of the viscera into SIT, situs solitus (isolated dextrocardia) and situs inversus viscerum, which is almost always associated with congenital heart disease, [4, 5]. Other rare form of SI, situs ambiguus typically manifests as either asplenia syndrome (right isomerism) or polysplenia syndrome (left isomerism). Many cardiovascular and renal anomalies have been reported in patients with SIT. Though the exact mechanism of the abnormal heart tube orientation and development is not fully understood there are documented linkages to chromosomal abnormalities (balanced reciprocal translocation t(5;11)(q32;q24.2), [6] and microdeletion of chromosome 2q37.3, [7]). Nearly 20–25% of the patients with SIT have syndrome of primary ciliary dyskinesia called Kartagener syndrome manifesting as repeated infections, bronchiectasis, and male infertility along with SIT, [4, 8].

There are several reported cases of cancers in patients with SI. A significantly high number of all the cancers that have been reported in patients with SIT have been from the gastrointestinal tract. Some of those have had much rarer forms of SIT like situs ambiguus, and polysplenia syndrome. There are also a handful of reports of double cancer involving different parts of the gut in patients with SIT. Amongst the patients with Kartagener syndrome there was a higher prevalence of lung cancer.

Although RCC is more commonly associated with other congenital syndromes such as Von Hippel-Lindau syndrome [9], hereditary papillary RCC [10], Birt-Hogg-Dube syndrome [11], there have been only four reported cases with SIT. Three of the previously reported RCC patients with SIT were cured with radical nephrectomy [12, 13]. Meticulous preoperative anatomical and vascular mapping and special precautions for airway management can overcome the surgical challenge posed by the presence of multiple anatomical anomalies and altered position of the blood vessels. Only one patient previously has received adjuvant chemotherapy with intramuscular interferon alfa and external beam radiation [14]. The presence of extensive metastatic disease, poor performance status and patient choices precluded more aggressive treatment choices in our case. There are no reports that confirm or refute the hypothesis that there is a causal association between situs inversus and the development of cancer.


Conclusion

Situs inversus is a rare congenital abnormality with an autosomal recessive inheritance pattern. In addition to renal anomalies and Kartagener syndrome, several types of malignancies co-exist in patients with situs inversus. RCC occurring in patients with situs inversus is a rare phenomenon and the association between these two conditions is unclear. Further study is needed to characterize the genetic basis of SI and establish whether there is a causal basis between SI and the development of malignancy.


Acknowledgement

The authors are grateful to Dr. Julian Crasta, M.D. Pathology for assistance with the pathological slides.


References
  1. Abossolo T, Alessandri JL, Saltet A, Dancoisne P, Pilorget H, Sommer JC. [In utero diagnosis of situs abnormalities. A case of prenatal diagnosis of visceral situs inversus with corrected transposition of great vessels]. J Gynecol Obstet Biol Reprod (Paris) 1996;25(3):267–3.   [Pubmed]    Back to citation no. 1
  2. European Network of Cancer Registries. Eurocim version 4.0. European incidence database V2.3, 730 entity dictionary 2001.    Back to citation no. 2
  3. Lina Liu, Junqi Qian, Harpreet Singh, Isabelle Meiers, Xiaoge Zhou, David G Bostwick. Immunohistochemical analysis of chromophobe renal cell carcinoma, renal oncocytoma, and clear cell carcinoma: an optimal and practical panel for differential diagnosis. Arch Pathol Lab Med 2007 Aug;131(8):1290–7.   [Pubmed]    Back to citation no. 3
  4. Casanova MS, Tuji FM, Yoo HJ, Haiter-Neto F. Kartagener syndrome. Dentomaxillofac. Radiol 2006;35(5):386–9.   [CrossRef]   [Pubmed]    Back to citation no. 4
  5. Chmura K, Chan ED, Noone PG, et al. A middle-aged woman with recurrent respiratory infections. Respiration 2005;72(4):427–30.   [CrossRef]   [Pubmed]    Back to citation no. 5
  6. Karaman A, Binici DN, Günes N, Doru I, Kabalar ME, Kurt A. A case with balanced reciprocal translocation t(5;11)(q32;q24.2) and situs inversus viscerum. Genet Couns 2010;21(2):237–42.   [Pubmed]    Back to citation no. 6
  7. Reddy KS, Flannery D, Farrer RJ. Microdeletion of chromosome sub-band 2q37.3 in two patients with abnormal situs Viscerum. Am J Med Genet 1999 Jun 11;84(5):460–8.   [CrossRef]   [Pubmed]    Back to citation no. 7
  8. Carlen B, Stenram U. Primary ciliary dyskinesia: a review. Ultrastructural Pathology 2005;29(3-4):217–20.   [CrossRef]   [Pubmed]    Back to citation no. 8
  9. Lonser RR, Glenn GM, Walther M, et al. von Hippel-Lindau disease. Lancet 2003;361(9374):2059–67.   [CrossRef]   [Pubmed]    Back to citation no. 9
  10. Zbar B, Tory K, Merino M, et al. Hereditary papillary renal cell carcinoma. J Urol 1994;151(3):561–6.   [Pubmed]    Back to citation no. 10
  11. Birt AR, Hogg GR, Dube WJ. Hereditary multiple fibrofolliculomas with trichodiscomas and acrochordons. Arch Dermatol 1977;113(12):1674–7.   [CrossRef]   [Pubmed]    Back to citation no. 11
  12. Adler HL, Lerner SP. Renal cell carcinoma and situs inversus viscerum. J Urol 1998 Dec;160(6 Pt 1):2141–2.   [Pubmed]    Back to citation no. 12
  13. Treiger BF, Khazan R, Goldman SM, Marshall FF. Renal cell carcinoma with situs inversus totalis. Urology 1993 May;41(5):455–7.   [CrossRef]   [Pubmed]    Back to citation no. 13
  14. Bertini JE Jr, Boileau MA: Renal cell carcinoma in a patient with situs inversus totalis. J Surg Oncol 1987 Jan;34(1):29–31.   [CrossRef]   [Pubmed]    Back to citation no. 14
