CASE REPORT

Macrodactyly of the right ring finger due to macrodystrophia lipomatosa: Pathologic and imaging characteristics
Elpis Mantadakis1, Savvas Deftereos2, Efthimios Sivridis3, Lambros Michailidis4, Athanassios Chatzimichael5, Panos Prassopoulos6
1Assistant Professor, Department of Pediatrics, Democritus University of Thrace and University General Hospital of Alexandroupolis, Thrace, Greece.
2Lecturer, Department of Radiology, Democritus University of Thrace and University General Hospital of Alexandroupolis, Thrace, Greece.
3Professor, Department of Pathology, Democritus University of Thrace and University General Hospital of Alexandroupolis, Thrace, Greece.
4Medical Student, Democritus University of Thrace Medical School, Alexandroupolis, Thrace, Greece.
5Professor, Department of Pediatrics, Democritus University of Thrace and University General Hospital of Alexandroupolis, Thrace, Greece.
6Professor, Department of Radiology, Democritus University of Thrace and University General Hospital of Alexandroupolis, Thrace, Greece.

doi:10.5348/ijcri-2011-04-27-CR-2

Address correspondence to:
Dr. Elpis Mantadakis
Assistant Professor of Pediatrics
Democritus University of Thrace and
University General Hospital of Alexandroupolis
6th Kilometre Alexandroupolis-Makris
68 100 Alexandroupolis
Thrace, Greece
Phone: +30-25510-74411
Fax: +30-25510-30340
Email: emantada@med.duth.gr

[HTML Abstract]   [PDF Full Text]

How to cite this article:
Mantadakis E, Deftereos S, Sivridis E, Michailidis L, Chatzimichael A, Prassopoulos P. Macrodactyly of the right ring finger due to macrodystrophia lipomatosa: Pathologic and imaging characteristics. International Journal of Case Reports and Images 2011;2(4):6-10.


Abstract
Introduction: Macrodystrophia lipomatosa (MDL) is a non-hereditary congenital developmental anomaly characterized by localized gigantism due to overgrowth of all mesenchymal elements.
Case Report: The authors describe a case of macrodystrophia lipomatosa (MDL) with involvement of the median nerve in a 10-year-old girl and review the pathologic, radiographic, ultrasonographic and MR imaging characteristics.
Conclusion: Ultrasonography and MR imaging are pathognomonic for MDL and reliably distinguish it from other forms of localized congenital gigantism. However, since ultrasonography has the advantages of much lower cost, portability and easy accessibility, we propose its use as the imaging modality of choice in the initial diagnostic approach of congenital localized gigantism.

Key Words: Typhoid glomerulonephritis, Typhoid fever, Nephritis, Acute renal failure


Introduction

Macrodystrophia lipomatosa (MDL) is a non-hereditary congenital developmental anomaly characterized by localized gigantism due to overgrowth of all mesenchymal elements. [1] It is characterized by an irregular increase of fibroadipose tissue in a neural distribution. The term MDL was initially coined by Feriz in 1925 to describe cases of lower-extremity gigantism that were associated with massive overgrowth of the accompanying adipose tissue. [2] Although MDL was originally described as primarily involving the peripheral parts of the involved extremities, it is now known that proximal parts of the extremities can also be affected.

We describe a case of MDL with involvement of the median nerve in a 10-year-old girl who was operated in another institution due to carpal tunnel syndrome and describe the pathologic and imaging characteristics of this condition.

Case Report

A 10-year-old girl was referred to us for an orthopedic and oncologic consultation by her pediatrician due to macrodactyly of the right ring finger. According to mother, the child's right ring finger started to grow at the age of six months. Over the last year along with the macrodactyly, she had noticed soft swelling of the ipsilateral volar aspect of the palm. Due to tingling in the distribution of the right median nerve, she was operated in another institution for carpal tunnel syndrome. Although she did not appreciate substantial improvement of her symptoms, she sought medical attention to us mainly for cosmetic reasons, since she was embarrassed from the macrodactyly to the point of avoiding school. Prior medical and family history was unremarkable. The initial physical examination confirmed the presence of macrodactyly (Figure 1) that was associated with the presence of soft, fibrolipomatous tissue in the outer half of the right palm. The remaining examination showed no cutaneous stigmata or organomegaly. Moreover, there were no bruits or edema in the involved extremity. Review of the slides from the tissue removed at surgery for carpal tunnel syndrome demonstrated excessive thickening of the perineurium of involved nerves, a characteristic finding of MDL (Figure 2). Plain radiographs showed soft tissue thickening and broadening of the second phalanx of the ring finger (Figure 3). After the initial examination, sonography was obtained that showed alternating hyperechoic and hypoechoic bands in a diffusely enlarged median nerve (Figure 4A and 4B).

Finally, MR imaging demonstrated longitudinally oriented cylindrical areas of low to intermediate signal intensity surrounded by adipose tissue in a diffusely thickened right median nerve, along with fat deposits in the muscles of the volar aspect of the right palm (Figure 5).

The patient remains mildly symptomatic, but after counseling and intense psychological support, she returned to school.

Click below to enlarge
Figure 1: Abdominal CT scan performed with administration of intravenous contrast media revealed a large, biphasic retroperitoneal hematoma (arrow).



Click below to enlarge
Figure 2: Hematoxylin and Eosin staining showing excessive thickening (arrows) of the perineurium of the involved nerve, a characteristic finding of MDL.



Click below to enlarge
Figure 3: Radiograph of the involved hand showing soft tissue thickening in the ring finger. Note the broadening of the second phalanx and the overgrowth of the distal phalanx in the same finger.



Click below to enlarge
Figure 4a: Axial sonogram of the wrist reveals cable-like thickening of the median nerve fascicles (arrows) with intervening hyperechoic fat.



Click below to enlarge
Figure 4b: Longitudinal sonogram (panoramic view) of the wrist reveals cable-like thickening of the median nerve fascicles (arrow) with intervening hyperechoic fat.



Click below to enlarge
Figure 5a: T1-weighted coronal MR image. Prominent subcutaneous fat along the right ring finger and palmar area.



Click below to enlarge
Figure 5b: T1-weighted axial MR image demonstrates cylindrical areas of low-intermediate signal intensity surrounded by adipose tissue in a diffusely thickened median nerve (arrow).



Discussion

MDL is commonly associated with fibrolipomatous infiltration of peripheral nerves, with the median and plantar nerves being the most frequently affected. [1] [2] [3] In these cases, we talk about fibrolipomatous hamartoma, i.e., an anomalous growth of fibroadipose tissue of the nerve sheath. Although fibrolipomatosis of the nerve can occur in isolation, i.e., without associated localized gigantism, in up to two thirds of the cases there is associated macrodactyly, and these cases are indistinguishable from MDL. Despite that, in MDL one entire extremity may be affected and abnormal fat deposits are not limited within the nerve sheaths but also involve the subcutaneous tissues, periosteum, and muscles. Some suggest that rather than MDL, the most appropriate term to describe lesions with associated localized gigantism is fibrolipomatous hamartoma of the nerve with macrodactyly. [3] Although overgrowth of all mesodermal elements of the digits is the dominant finding in MDL, associated clinical findings such as polydactyly can occur. [1]

In most reported cases to date, the lesions are present at birth or develop within the first weeks of life. The lesions are unilateral and associated with uneven and progressive overgrowth that is more rapid compared to the rest of the limb. Cases with bilateral involvement have been described, but are extremely rare. [4]

Radiographs reveal soft-tissue and osseous overgrowth often with elongated, broadened, and splayed phalanges.[5] The imaging appearance, particularly with sonography and MR imaging of advanced lipomatosis of a nerve is usually distinctively characteristic and reflects the underlying disease. Sonography reveals alternating hyperechoic (fat) and hypoechoic (nerve fascicles) bands in a diffusely enlarged nerve, thus creating a cable-like appearance. [6] [7] MR images are similar, with longitudinally oriented cylindrical areas of low to intermediate signal intensity (nerve fascicles) surrounded by adipose tissue in a diffusely thickened nerve. [8] On MR images, increased fat content of the digits is also apparent in patients with macrodactyly. MR imaging is considered pathognomonic of MDL and, therefore, is advisable in the diagnostic approach of localized gigantism with questionable clinical features. [8] [9] However, according to the findings of the present case, US may be adequate for a prompt diagnosis. A high frequency ultrasound study resulting in high resolution images can disclose specific alterations of the nerve with a "cable-like" appearance and an increased accumulation of hyperechoic fat tissue. Therefore, we suggest that clinical evaluation and ultrasound examination can safely diagnose MDL, obviating the necessity of further MR imaging. The pathology of MDL is quite characteristic. The normal perineurium surrounding the nerve fascicles creates a barrier separating the nerve axons within the fascicle from the surrounding adipocytes. In MDL, this perineural fibrotic layer is excessively thickened compared with the normal unaffected tissue, a characteristic finding that was seen in our patient. Because MDL usually regresses to a static lesion on completion of a child's growth, if surgery is to be performed it is usually delayed until growth has stopped. However, there have been cases of continuous enlargement into adulthood. Hence, in symptomatic patients proper counseling should discuss the possibility for re-operations into adult life, something that was done in our case.

MDL should be differentiated from other forms of congenital localized gigantism such as Klippel-Trenaunay syndrome (KTS), Proteus syndrome and neurofibromatosis. Although the definition of KTS is not universally agreed and even though it does not always include localized gigantism, varicose veins and an anomalous lymph system are usually present along with hypertrophy of the bones and soft tissues. Plain x-rays shows soft tissue and bone enlargement, while phleboliths may be seen within the vascular malformations. [9] MRI is a non-invasive method of identifying the presence and extent of vascular anomalies in KTS. These tend to be of high signal on T2 weighted images, although areas of low signal can be seen and represent hemosiderin deposits or areas of calcification. Proteus syndrome, also known as Wiedemann's syndrome is characterized by mosaic overgrowth of skin, bones, muscles, fatty tissues, blood and lymphatic vessels, as well as by visceromegaly, lung cysts, and predisposition to benign and malignant tumors. A characteristic finding is the disorganization and distortion of skeletal structures, a finding that contrasts with more common forms of osseous overgrowth in which the enlarged bones retain their normal proportional relationships. [10] Finally, in neurofibromatosis cutaneous manifestations of the disease (café au lait macules, neurofibromas, freckling in the axillary and inguinal regions) and positive family history, i.e. a first-degree relative with type 1 neurofibromatosis are typically present. T2-weighted MR images show hyperintense neurofibromas situated close to the affected nerve.

Conclusion

In conclusion, we describe a case of progressive macrodactyly due to MDL and present its pathologic and imaging findings. Even though history and physical examination are usually diagnostic, both ultrasonography and MR imaging can reliably distinguish MDL from other forms of localized congenital gigantism. However, since ultrasonography has the advantages of much lower cost, portability, and easy accessibility, we propose its use as the imaging modality of choice in the initial diagnostic approach of congenital localized gigantism.

References
  1. Goldman AB, Kaye JJ. Macrodystrophia lipomatosa: radiographic diagnosis. AJR Am J Roentgenol 1977;128:101-105.   [Pubmed]    Back to citation no. 1
  2. Feriz H. Macrodystrophia lipomatosa progressive. Virchows Arch Pathol Anatomic Physiol Clin Med 1925;260:308-368.    Back to citation no. 2
  3. Silverman TA, Enzinger FM. Fibrolipomatous hamartoma of nerve. A clinicopathologic analysis of 26 cases. Am J Surg Pathol 1985;9:7-14.   [Pubmed]    Back to citation no. 3
  4. Aydos SE, Fitoz S, Bökesoy I. Macrodystrophia lipomatosa of the feet and subcutaneous lipomas. Am J Med Genet A 2003;119A:63-65.   [CrossRef]   [Pubmed]    Back to citation no. 4
  5. Gupta SK, Sharma OP, Sharma SV, Sood B, Gupta S. Macrodystrophia lipomatosa: radiographic observations. Br J Radiol 1992;65:769-773.   [CrossRef]   [Pubmed]    Back to citation no. 5
  6. Stuart RM, Koh ES, Breidahl WH. Sonography of peripheral nerve pathology. AJR Am J Roentgenol 2004;182:123-129.   [Pubmed]    Back to citation no. 6
  7. Soler R, Rodríguez E, Bargiela A, Martinez C. MR findings of macrodystrophia lipomatosa. Clin Imaging 1997;21:135-137.   [CrossRef]   [Pubmed]    Back to citation no. 7
  8. Blacksin M, Barnes FJ, Lyons MM. MR diagnosis of macrodystrophia lipomatosa. AJR Am J Roentgenol 1992;158:1295-1297.   [Pubmed]    Back to citation no. 8
  9. D'Costa H, Hunter JD, O'Sullivan G, O'Keefe D, Jenkins JP, Hughes PM. Magnetic resonance imaging in macromelia and macrodactyly. Br J Radiol 1996;69:502-507.   [Pubmed]    Back to citation no. 9
  10. Jamis-Dow CA, Turner J, Biesecker LG, Choyke PL. Radiologic manifestations of Proteus syndrome. Radiographics 2004;24:1051-1068.   [CrossRef]   [Pubmed]    Back to citation no. 10

[HTML Abstract]   [PDF Full Text]

Author Contributions:
Elpis Mantadakis - Conception and design, Acquisition of data, Analysis and interpretation of data, Drafting the article, Critical revision of the article, Final approval of the version to be published
Uduman Ali Mohamed Yousuf - Substantial contributions to conception and design, Analysis and interpretation of data, Drafting the article, Final approval of the version to be published
Savvas Deftereos - Acquisition of data, Analysis and interpretation of data, Critical revision of the article, Final approval of the version to be published
Efthimios Sivridis - Analysis and interpretation of data, Critical revision of the article, Final approval of the version to be published
Lambros Michailidis - Acquisition of data, Drafting the article, Final approval of the version to be published
Athanasios Chatzimichael - Analysis and interpretation of data, Critical revision of the article, Final approval of the version to be published
Panos Prassopoulos - Analysis and interpretation of data, Critical revision of the article, Final approval of the version to be published
Guarantor of submission:
The corresponding author is the guarantor of submission.
Source of support:
None
Conflict of interest:
The author(s) declare no conflict of interests
Copyright:
© Elpis Mantadakis et. al. 2010; This article is distributed the terms of Creative Commons attribution 3.0 License which permits unrestricted use, distribution and reproduction in any means provided the original authors and original publisher are properly credited. (Please see Copyright Policy for more information.)
